Additional information
| Specifications | Constructional features of the pump Technopolymer pump body and die-cast aluminium motor support. Technopolymer impeller, diffuser, Venturi tube and sand guard. Stainless steel pressure disc. Carbon/ceramic mechanical seal. |
|---|---|
| Highlights | Constructional features of the motor Induction motor, closed and cooled with external ventilation. Rotor mounted on oversized greased sealed-for-life ball bearings to ensure silent running and long life. Built-in thermal and current overload protection and a capacitor permanently in circuit in the single-phase version. Three-phase motors should be protected with a suitable overload protection complying with the regulations in force. Manufactured according to CEI 2-3 and CEI 61-69 standards (EN 60335-2-41). Motor protection: IP 44 Terminal box protection: IP 55 Insulation class: F Standard voltage: single-phase 220-240 V/50 Hz three-phase 230-400 V/50 Hz |
| Volts | 240V |
| Warranty | 2 year DAB PUMP warranty |
| Kw Output | 0.45, 0.55, 0.75, 0.80, 1.00, 1.10, 1.50, 1.85, 2.20, 3.00 |
| Horse Power | 0.6, 0.8, 1.0, 1.1, 1.36, 1.5, 2.0, 2.5, 3.0, 4.0 |
| Brand | DAB |
| Model Number | DAB-KVCX35/30 MPP, DAB-KVCX50/30 MPP, DAB-KVCX70/30 MPP, DAB-KVCX30/50 MPP, DAB-KVCX55/50 MPP, DAB-KVCX75/50 MPP, DAB-KVCX30/80 MPP, DAB-KVCX45/80 MPP, DAB-KVCX55/80 MPP, DAB-KVCX55/80T, DAB-KVCX65/80T, DAB-KVCX35/120 MPP, DAB-KVCX45/120 MPP, DAB-KVCX45/1 |
